IN SLAB ELECTRIC UNDERFLOOR HEATING

web_image_producthero_elecslab

In-slab electric floor heating is a very practical option for warming large areas. It is used in homes and commercial buildings because it offers an excellent cost and energy efficient solution for large spaces.

APPLICATIONS

The in-slab heating cable is suitable where the slab is used as a heat storage [thermal mass]. It has a slow response time and can take 10-24 hours to heat up, depending on slab thickness and insulation, but retains heat for a long time after power has terminated. Off-peak power is typically utilised for in-slab heating.

CABLE TECHNOLOGY

The cable is a flexible, double-insulated single cable system. A multi-strand heating cable provides superior strength to prevent cable failure due to slab movement.

HEAT OUTPUT

The in-slab cable has a heat output of 160W /m² at 200mm spacing. It is available in factory terminated lengths ranging from 30m up to 170m. Comfort Heat staff will help select the correct cable length for your heated area with a 200mm clearance from walls and fixtures.

INSTALLATION

The cable is installed before the slab is poured attached to either the mesh (i.e. F72) or the reinforcing rods installed at 200mm centres (one direction only).

SPECIAL REQUIREMENTS

The cable cannot be installed across expansion joints. Comfort Heat must be informed of any expansion joints in the slab. For large areas, multiple cables will be installed.



Talk to Us about In Slab Electric Underfloor Heating

For more information about the latest modern floor heating, download our brochures. To discuss your options for in slab underfloor heating, call us or contact us online. We’ll be happy to provide any information, technical guidance, or services you require.

Please note: In slab underfloor heating requires site information and metrics. We’ll require information about your slab construction and measurements to provide you with technical support and a quote.



TECHNICAL DATA

Cable Type : Single conductor heating cable with earth screen
Construction : Multi-stranded heating wire with double insulation, earth screen and sheath
Insulation : 4000 V
Rated Voltage : 230 Volt AC; Rated output 30W/m
Cold Tail Length : 3.5 metre with splice connection
Cable Diameter : 5mm
Cable Standard : IEC800 Class II
Warranty : 10 years
