MIRROR HEAT

img_hero_mirror

Mirror heat pads are specially designed to eliminate mirror condensation after a steamy shower, allowing for a clear mirror appearance. The ultra-thin heating element is designed to be taped on the rear of your mirror before being mounted on the wall.

Mirror heat pads come in 2 sizes and large mirrors and combine two pads side by side to expand clear viewing.



SIZES AND HEAT OUTPUT

360mm x 500mm 50W 240V
570mm x 750mm 100W 240V
390mm x 460mm
(includes.transformer)
50W 24V



INSTALLATION

Mirror Heat pads are taped to the back of the mirror before hanging. Mirror Heat pads are hard wired directly to a standard on/off switch. Mirror Heat must be installed and connected in accordance with standards AS/NZ3000:2000. Electrical work must be carried out by a licensed electrician.On/Off switch is not supplied by Comfort Heat.





TECHNICAL DATA

Heater Type Double insulated polyester film. Aluminium based heating element etched to surface
Supply Voltage 230/240V
Heater Thickness 0.4mm (Connection point 2mm)
Cable Length 1000mm
Protection IP34 class 2
Surface Temperature Approx. 30 deg C (45 deg C max)
Warranty 5 years



BROCHURE DOWNLOADS

E-brochure_Mirror Heat
